RAB Design’s All-in-One Canopy Light
We get it. In the past, lighting catalogues were more dense than your city’s Yellow Pages. Google that if you’re under 20, but it was a very large book.
A million fixture types, voltage configurations, colour temperatures, and all you want to do is light up a parking garage. RAB Design has you covered.
RAB’s ultra-flexible line of Canopy Lights come in both square (SCL series) and round (RCL series) form factors, and have selectable colour temps from 3000K to 5000K.
When you add a built-in dimming functionality with 0-10V input, custom housing colours available, built-in motion sensors, and a 120-347V input range, you have the true All-In-One Canopy Light. You’ll never have to ask, “Will this Canopy fixture work for my job?” again, and instead wonder where RAB Design has been all your life.
| Model | SCL1S-LED70A45 |
|---|---|
| Tested Wattage (Maximum) | 46.76W |
| Tested Lumens (Maximum) | 6586lm |
| Efficacy | 140.8 lm/W |
| Voltage | 120-347V |
| CCT | Variable Kelvin (3000K/4000K/5000K) |
| CRI | 74 |
| Dimming | 0-10V Dim (10%-100%) |
| Power Factor | ≥0.90 |
| LED Life (L78) | 100,000 Hours |
| Finish | Bronze |
| Housing Details | Die Cast Aluminum |
| Lens Details | Polycarbonate |
| B-U-G Rating | B2-U0-G1 |
| Mounting | Surface/Pendant mount |
| Number of Conduit Entries | 3 - 1/2” NPT (Sides) and 1 - 3/4” NPT (Back) |
| Operating Temp. | -40°C to +40°C (-40°F to 104°F) |
| Factory Installed Options | Dimming High Frequency Motion Sensor, 9W Battery Back up (SCL1S-LED45A23 only) |
| Certifications | UL, Wet Location, IP65, DLC Premium |
