RAB Design Flood Lights
FLV LED Series
| Model | FL1V-LED16 |
|---|---|
| Watts | 14.95W |
| Lumens | 1402.8 Lm |
| Efficacy (Lumens/Watt) | 93.85 Lm/W |
| Voltage | 120V |
| CCT | 4000K |
| CRI | 72 |
| THD | 14.50% |
| Power Factor | 0.988 |
| Beam Distribution | NEMA 7H x 7V |
| LED Life (L78) | 100,000 hours |
| Housing Finish | Bronze |
| Housing Details | Die Cast Aluminum |
| Lens Details | Semi Frosted Polycarbonate |
| Mounting | Knuckle, Yoke |
| Cable Length | Yoke - 0.5m of Cabtire Cable (SJTW 3 x 18AWG) Knuckle - 0.15m of Supply Wires |
| Operating Temp. | -40°C to +40°C (-40°F to 104°F) |
| Certifications | UL, Wet Location, IP65, 3 Year Warranty |
Nothing takes a building’s exterior from drab to wow better than a good flood light. And RAB Design DEFINITELY knows good flood lights. The FLV is the compact wide-beam workhouse for every patio, landscape or general flood application. It's a 15W fixture that replaces traditional 150W quartz fixtures and is rated down to –40C.
For more serious and large-scale lighting applications, the RFLV series from RAB is the Performance standard for Flood Lights in Canada. With the RFLV, you can choose a wide beam NEMA 6X6 for a large and uniform light area, or a NEMA 4X4 for accenting specific architectural or design items. Choose between ½" knuckle mount or yoke mount, and optionally add a visor or wireguard to fit the environmental requirements, and you’re done. The RFLV is field selectable in colour warmth from 3000k to 5000k, 0-10V dimmable, comes with built-in (and easily bypassed) photocell, and takes 120-277V input. All that in one Flood Light? Yes, with RAB Design.
RFLV LED Series
| Model | RFL1V-LED20 |
|---|---|
| Watts | 20.43W |
| Lumens | 2957 Lm |
| Efficacy (Lumens/Watt) | 144.7 Lm/W |
| Voltage | 120V-277 |
| CCT | 3000K/4000K/5000K |
| CRI | 72 |
| Dimming | 0-10V Dim to Off |
| THD | 15.14% |
| Power Factor | 0.980 |
| Beam Distribution | Wide (NEMA 6x6), Narrow (NEMA 4x4) |
| LED Life (L80) | >72000 hours |
| Housing Finish | Bronze, custom colours |
| Housing Details | Die Cast Aluminum |
| Lens Details | Clear Polycarbonate Lens |
| Mounting | Knuckle, Yoke |
| Cable Length | 1m of Cabtire Cable (SJTW 5 x 18AWG) |
| Operating Temp. | -40°C to +40°C (-40°F to 104°F) |
| Factory Installed Options | 10kV Surge Suppressor |
| Options Sold Separately | Yoke, Knuckle, Wire Guard, Visor |
| Certifications | UL, Wet Location, IP65, DLC |
